Mercedes Sprinter Mk2 906 SRS airbag warning light - indicates a problem within the airbag system and needs to be checked out ASAP. You should use a diagnostic tool which covers the airbag system such as the the iCarsoft MB V1.0 Mercedes OBD Code Reader. The kit will tell you where within the airbag system the fault is occuring, and also allow you to clear the dashboard airbag light.

Mercedes Sprinter Mk2 906 ABS warning light - indicates a problem within the ABS or Anti Lock Braking System. You need to hook this upto a diagnostic kit that covers the ABS module such as the iCarsoft MB V1.0 Mercedes OBD Code Reader kit . It could be that an ABS sensor needs to be replaced - if this is the case you should visit www.bavariandominator.co.uk for your ABS sensors

Mercedes Sprinter Mk2 906 LIVE DATA - to retrieve live data stream from your Mercedes Sprinter 906 we highly recommend using the iCarsoft MB V1.0 Mercedes OBD Code Reader. It will allow you to read live data such as throttle position, IAT, o2 sensor 1, o2 sensor 2, o2 sensor 3, o2 sensor 4, RPM, fuel trim, coolant temperature, transmission fluid temperature and much more.

Mercedes Sprinter Mk2 906 water in fuel warning light - this symbol indicates that water has made its way into the water seperator. Remove the seperator and remove the water from the system.

Mercedes Sprinter Mk2 906 glowplugs pre heating warning light - the glowplugs preheating symbol in your Mercedes Sprinter will only occur in diesel vehicles. When you turn on the ignition you should wait till this light turns off before starting engine. If the light remains on the dash for a long time, or does not turn off at all it could mean that one or more glowplugs are faulty and need to be replaced. This is what often causes the Sprinter to start slowly, or crank a lot before startng. To diagnose glowplug faults you can use the iCarsoft MB V1.0 Mercedes OBD Code Reader. It might not be the glowplugs but it might be the glowplug module/ECU. The i980 kit will allow you to read & clear fault codes and turn off the dash warning light.

Mercedes Sprinter Mk2 906 (P) PARK warning light - indicates that the parking brake is in the ON position.

Mercedes Sprinter Mk2 906 low oil pressure warning light - the oil pressure symbol in the Mercedes Sprinter indicates that the oil level could be low. Use the dipstick to check oil level and top up accordingly.

Mercedes Sprinter Mk2 906 dirt in air filter - this symbol in your Mercedes Sprinter indicates there is dirt in the air filter and it should be cleaned in order to improve MPG and engine performance.

Mercedes Sprinter Mk2 906 DEF LOW warning light - this is the Diesel Exhaust Fluid warning symbol which will illuminate on your Sprinter if the fluid is low. You should check levels and top up accordingly.

Mercedes Sprinter Mk2 906 coolant level low - this is the low coolant level symbol in the Sprinter and indicates that you should top up your expansion tank as soon as possible with coolant to prevent the engine from overheating and causing damage.

Mercedes Sprinter Mk2 906 brake pads warning light - the brake pads symbol in your Mercedes Sprinter means that the brake pads should be inspected and replaced as soon as possible.

Mercedes Sprinter Mk2 906 battery warning light - the battery symbol in your Sprinter indicates that there is a malfunction in the charging system. Do not always assume that the battery needs to be replaced because it could be something else in the charge system that has become faulty and needs to be replaced. Have it checked out by a professional.

Mercedes Sprinter Mk2 906 ASR/BAS warning light - the ASR/BAS symbol when illuminated means this system has been de-activated. You can diagnose a fault in this system by using the iCarsoft MB V1.0 Mercedes OBD Code Reader.

Mercedes Sprinter Mk2 906 ADR warning light - the ADR symbol hen activated, the working speed governor (ADR) automatically increases the engine speed to a preset or adjustable speed.

Mercedes Sprinter Mk2 906 coolant warning light - the coolant symbol like this means that the temperature is too high and you should pull over immediately and not drive any further to prevent engine damage. Check for leaks coming from the expansion tank, and fill up with coolant if possible. If this does not solve the issue please have it checked at your local Mercedes dealership or local garage.

Mercedes Sprinter Mk2 906 traction control warning light - indicates a fault within the traction control system if illuminated while the car is driving over tarmac road. You can diagnose the fault in this system by using the iCarsoft MB V1.0 Mercedes OBD Code Reader kit. It will give you a unique fault code and description for the fault. It will also allow you to erase the trouble codes and reset the warning light on the dashboard.

Mercedes Sprinter Mk2 906 tyre pressure warning light - check your tyre pressures as one or more tyres needs to be pumped up.

Mercedes Sprinter Mk2 906 brake warning light - there is not enough brake fluid in the brake fluid reservoir.
The braking effect may be impaired.
There is a risk of an accident.
- Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions. Do not continue driving under any circumstances.
- Secure the vehicle against rolling away
Do not add brake fluid. Topping up will not remedy the malfunction.
- Consult a qualified specialist workshop.
- Observe the additional display messages in the multifunction display.

Mercedes Sprinter Mk2 906 warning light - this light is normally accompanied by other warning lights on your dashboard.
