Ford C-Max Mk2 airbag warning light - indicates a problem within the airbag system and needs to be checked out ASAP. You should use a diagnostic tool which covers the airbag system such as the iCarsoft i920 Ford OBD Code Reader. The kits will tell you where within the airbag system the fault is occuring, and also allow you to clear the dashboard airbag light.

Ford C-Max Mk2 ABS Dash Light - indicates a problem within the ABS or Anti Lock Braking System. You need to hook this upto a diagnostic kit that covers the ABS module such as the iCarsoft i920 Ford OBD Code Reader. It could be that an ABS sensor needs to be replaced - if this is the case you should visit www.bavariandominator.co.uk for your ABS sensors

Ford C-Max Mk2 coolant dash warning light - if it stays on after starting or illuminates when driving, this indicates a malfunction. Stop your vehicle as soon as it is safe to do so and switch the engine off. Check the coolant level.

Ford C-Max Mk2 engine oil pressure warning light - illuminates when the oil pressure falls below the normal range. Check you oil levels and top up if neccesary.

Ford C-Max Mk2 rear fog lamp dash warning light - it will illuminate when you switch
the rear fog lamps on.

Ford C-Max Mk2 I or Information dash warning light - it will illuminate when a new message is stored in the information display

Ford C-Max Mk2 up shift gear dash warning light - it will illuminate to inform you that shifting to a higher gear may give better fuel economy and lower CO2 emissions. It will not illuminate during periods of high acceleration, braking or when the clutch pedal is pressed.

Ford C-Max Mk2 front fog light dash warning light - it will illuminate when you switch
the front fog lamps on.

Ford C-Max Mk2 forward alert dash warning light - it will illuminate when this feature is switched off.

Ford C-Max Mk2 headlight beam dash warning light - it will illuminate when you switch the headlamp dipped beam

Ford C-Max Mk2 glow plugs or pre heating dash warning light - will illuminate when outside air temperature is low. The light will illuminate at first, then go out when it is safe to start the engine, available on diesel engines only.

Ford C-Max Mk2 frost dash warning light - it will illuminate and glow orange when the outside air temperature is between 4ºC (39.2ºF) and 0ºC (32ºF). It will glow red when the temperature is below 0ºC (32ºF).

Ford C-Max Mk2 blind spot monitor dash warning light - it will illuminate when this feature is switched off or in conjunction with a message.

Ford C-Max Mk2 direction indicator warning lights - speaks for itself really.

Ford C-Max Mk2 lane assist dash warning light - it will illuminate when this feature is switched off or in conjunction with a message. The indicator will go out when you switch the system back on or when you switch the ignition off.

Ford C-Max Mk2 high beam - illuminates when the high beam has been turned on.

Ford C-Max Mk2 low fuel warning light - fill up your fuel tank you are about to run out.

Ford C-Max Mk2 traction warning light - while driving, it flashes during activation of the system. After switching on the ignition, if it does not illuminate or illuminates continuously while driving, this indicates a malfunction.
During a malfunction, the system switches off. Have the system checked by a properly trained technician as soon as possible or you can diagnose the system yourself by using the iCarsoft i920 Ford OBD Code Reader.

Ford C-Max Mk2 battery warning light - if this is lit up during normal operating conditions it indicates that the battery is not being charged. This needs to be checked out by your local workshop.

Ford C-Max Mk2 seatbelt warning light - you or your passenger needs to fasten your seatbelt.
