Toyota Rav 4 airbag warning light - the airbag symbol lamp on the Toyota Rav 4 will illuminate when there is a fault within the airbag SRS system, it could be something like a loose connection, or something more serious. The best way to check this out is by using the iCarsoft TYT V1.0 Toyota OBD Code Reader tool which will communicate with the airbag system and tell you exactly where the fault is located. Once the fault has been corrected the airbag fault codes can be erased and the warning light can be removed from the dash. If you are UK driver and you present your Rav for for an MOT with the airbag light on - it will fail. So you should take the steps to remove it before the MOT.

Toyota Rav 4 ABS warning light - the ABS warning lamp on the Rav 4 will mean that there is a fault somewhere in the ABS system. The fault is generally because of an ABS sensor which needs to be replaced, but could be something more serious like a faulty ABS pump or ABS module ECU. You can find the exact fault location with the iCarsoft TYT V1.0 Toyota OBD Code Reader which will allow you to find & erase the fault, which will remove the ABS light once the fault has been fixed. In the UK the RAV 4 will fail an MOT if the ABS light is illuminated when presented for test.

Toyota Rav 4 VSC TRAC warning light - the VSC TRAC symbol lamp warns that there is a problem somewhere in the vehicle stability control system or traction control system. The light will come on when the ignition key is turned to “ON” and will go off after a few seconds. If the light comes on while driving, the system does not work. However, as conventional braking operates when applied, there is no problem to continue your driving.

Toyota Rav 4 battery discharge warning light - the battery symbol means that the battery is being discharged. If it comes on while you are driving, there is a problem somewhere in the charging system. The engine ignition will continue to operate, however, until the battery is discharged. Turn off the air conditioning, blower, radio,etc., and have your electrical system diagnosed by your local Toyota repair shop.

Toyota Rav 4 flat tyre or pressure monitor warning light - this symbol lamp will illuminate when the system detects that one of more tyres is not inflated correctly. Please check your tyre pressures and top up accordingly.

Toyota Rav 4 TRAC OFF warning light - the TRAC OFF symbol lamp is only present in 2 wheel drive models and will illuminate when the TRAC OFF button is not pushed.

Toyota Rav 4 slip indicator or traction warning light - the traction symbol lamp will illuminate when driving on a surface such as snow or ice, it will flash to show that the system is trying to acheive maximum traction on the road. If the warning light is illuminated permanently it indicates there is a fault in the system and should be checked out. You can do this yourself with the iCarsoft TYT V1.0 Toyota OBD Code Reader or you can take it to your local Toyota workshop.

Toyota Rav 4 seatbelt warning light - indicates that the driver has not fastened their seatbelt.

Toyota Rav 4 passenger seatbelt warning light - indicates that one or more passenger has not fastened their seatbelt.

Toyota Rav 4 open door warning light - simply indicates that one or more door is open and they should be checked before you continue your journey.

Toyota Rav 4 oil pressure warning light - the oil symbol lamp means that there is not enough oil in the engine and you should check your oil levels as soon as possible to prevent any engine damage. To make sure you are using the correct oil please use our correct engine oil guide.

Toyota Rav 4 O/D OFF warning light - this warning simly indicates that the overdrive system has been switched off.

Toyota Rav 4 MAINT REQD warning light - this warning light indicates that engine oil replacement is required. When you see this light you would be best advised to also change service items such as air filters, oil filter & possible spark plugs.

Toyota Rav 4 fuel warning light - the fuel symbol lamp on the dash of your Rav 4 indicates that you are low on fuel and need to fill up as soon as possible.

Toyota Rav 4 brake ! warning light - the brake or ! symbol lamp indicates that there is a fault within the braking system. You should first check your brake fluid and top up if required. You might also find that these symbols will illuminate with the ABS warning light (see ABS section above)

Toyota Rav 4 A/T oil temp warning light - the A/T oil temp symbol lamp indicates that the temperature of the transmission oil needs to be looked at, you should take it to your Toyota workshop to be investigated.

Toyota Rav 4 automatic transmission indicator lights
